# Spectra

The Spectra object stores complex spectra as created by the functions CreateSpectra or CreateResonantSpectra. The spectra are stored as complex functions on a discrete mesh. The object furthermore contains several additional information such as the integral.

## Shared code for examples

In order to run the examples for the different functions, properties and methods of the object spectra we define a set of functions specific to spectra. These functions must be loaded before any of the examples provided later on will work. The code creates three spectra stored in the variable G

1. a spectrum with 9 peaks at energy 1 to 9 in steps of 1 and intensity 0.12 to 0.92.
2. a spectrum with 4 peaks at energy 2 to 8 in steps of 2 and intensity 0.22 to 0.82.
3. a spectrum with 5 peaks at energy 1 to 9 in steps of 2 and intensity 0.12 to 0.92.

The actual code in Quanty is:

definitions.Quanty
NF = 9
NB = 0
T1 = NewOperator("Create", NF, {0,1,2,3,4,5,6,7,8},{0.1,0.2,0.3,0.4,0.5,0.6,0.7,0.8,0.9})
T2 = NewOperator("Create", NF, {0,1,2,3,4,5,6,7,8},{0.0,0.2,0.0,0.4,0.0,0.6,0.0,0.8,0.0})
T3 = NewOperator("Create", NF, {0,1,2,3,4,5,6,7,8},{0.1,0.0,0.3,0.0,0.5,0.0,0.7,0.0,0.9})
H = NewOperator("Number", NF, {0,1,2,3,4,5,6,7,8}, {0,1,2,3,4,5,6,7,8}, {1,2,3,4,5,6,7,8,9})
psi = NewWavefunction(NF,NB,{{"000000000",1}})
G = CreateSpectra(H, {T1,T2,T3}, psi, {{"Emin",-1}, {"Emax",11}, {"Gamma",0.1}})
set autoscale
set xtic auto
set ytic auto
set style line  1 lt 1 lw 1 lc rgb "#000000"
set style line  2 lt 1 lw 1 lc rgb "#FF0000"
set style line  3 lt 1 lw 1 lc rgb "#00FF00"
set style line  4 lt 1 lw 1 lc rgb "#0000FF"
set style line  5 lt 1 lw 3 lc rgb "#808080"
set style line  6 lt 1 lw 3 lc rgb "#00FFFF"
set style line  7 lt 1 lw 3 lc rgb "#FF00FF"
set style line  8 lt 1 lw 3 lc rgb "#FFFF00"
set xlabel "Energy (arb. units)" font "Times-Roman,12"
set ylabel "Intensity (arb. units)" font "Times-Roman,12"
set size 1.0, 0.3
set terminal postscript portrait enhanced color  "Times-Roman" 8
]]

The code above does not create output. We can save the spectra G to file and use gnuplot to plot the spectra with the example below.

Example.Quanty
dofile("definitions.Quanty")
G.Print({{"file","Spectra.dat"}})
set output "Spectra.ps"
plot "Spectra.dat"  using 1:(-$3 ) title 'T1' with lines ls 1,\ "Spectra.dat" using 1:(-$5+4) title 'T2' with lines ls  2,\
"Spectra.dat"  using 1:(-\$7+8) title 'T3' with lines ls  3
]]
file = io.open("Spectra.gnuplot", "w")
file:write(gnuplotScript)
file:close()
-- call gnuplot to execute the script
os.execute("gnuplot Spectra.gnuplot")
os.execute("convert -density 1024 Spectra.ps -resize 1024 Spectra.png")

The resulting picture is:
